OPT HPE 652497-B21 SCHEDA DI RETE ETHERNET 1GB 2P 361T PCIE

Descrizione

Generale
Tipo di dispositivo
Adattatore di rete

Fattore di forma
Scheda plug-in – profilo basso

Tipo di interfacia (Bus)
PCI Express 2.0 x4

Revisione specifiche PCI
PCIe 2.0

Networking
Porte
Gigabit Ethernet x 2

Tecnologia di connessione
Cablato

Tipo cablaggio
Ethernet 10Base-T,Ethernet 100Base-TX,Ethernet 1000Base-T

Data Link Protocol
Ethernet,Fast Ethernet,Gigabit Ethernet

Velocità di trasferimento
1 Gbps

Protocollo di gestione remota
SNMP

Indicatori di stato
Velocità trasmissione porta,collegamento/attività

Caratteristiche
Auto-negotiation,wake on LAN (WOL),tolleranza guasti sulla rete (NFT – network fault tolerance),supporto Jumbo Frame,supporto per PXE,Large Send Offload (LSO),Energy Efficient Ethernet

Standard di conformità
IEEE 802.3,IEEE 802.3u,IEEE 802.1Q,IEEE 802.3ab,IEEE 802.3x,IEEE 802.3ad (LACP),IEEE 802.1as,IEEE 802.3az

Processore / Memory
Processore
1 x Intel I350

Espansione/connettività
Interfacce
2 x 1000Base-T – RJ-45

Slot compatibili
1 x PCI Express 2.0 x4 – di piccole dimensioni

Miscellanea
Accessori in dotazione
Staffa a basso profilo

Standard di conformità
Con certificazione FCC Classe B,UL,VCCI Class B ITE,CISPR 22 Class B,DOC-B,EN 60950,UL 1950,VCCI-II,WHQL,EN55022 Class B,ICES-003 Class B,MIC Class B,WEEE,RoHS,BSMI Class A

Software / Requisiti di sistema
Sistema operativo richiesto
SUSE Linux Enterprise Server,Microsoft Windows Server 2008,Microsoft Windows HPC Server 2008,Oracle Solaris 10,Red Hat Enterprise Linux 6.1,VMware ESX 4.1,VMware ESXi 4.1,VMware ESXi 5,Red Hat Enterprise Linux 5.7,Citrix XenServer 6.0

Dimensioni e peso
Profondità  13.5 cm
Altezza  6.4 cm

Parametri ambientali
Temperatura min esercizio  0 °C
Temperatura max esercizio  55 °C
Umidità ambiente operativo  10 – 95% (senza condensa)

Informazioni sulla compatibilità
Progettato per
HPE Apollo 4200 Gen10
HPE ProLiant DL180 Gen10 SMB,DL180 Gen9 Storage,DL20 Gen10,DL20 Gen10 Entry,DL20 Gen10 Performance,DL20 Gen10 solution,DL20 Gen9,DL20 Gen9 Entry,DL20 Gen9 Performance,DL20 Gen9 Solution,DL325 Gen10 Base,DL325 Gen10 Solution,DL360 Gen10,DL360 Gen10 Base,DL360 Gen10 Entry,DL360 Gen10 High Performance,DL360 Gen10 Low,DL360 Gen10 Network Choice,DL360 Gen10 Performance,DL360 Gen10 SMB,DL360 Gen10 SMB Network Choice,DL360 Gen10 Solution,DL360p Gen8,DL360p Gen8 CMS,DL360p Gen8 Special Server,DL380 Gen10,DL380 Gen10 Base,DL380 Gen10 Entry,DL380 Gen10 Entry SMB,DL380 Gen10 for Cohesity DataPlatform,DL380 Gen10 High Performance,DL380 Gen10 Network Choice,DL380 Gen10 NVMe All Flash Server for Datera,DL380 Gen10 Performance,DL380 Gen10 SMB,DL380 Gen10 SMB Networking Choice,DL380 Gen10 Solution,DL380 Gen9 High Performance,DL388 Gen10 Network Choice,DL560 Gen10,DL560 Gen10 Base,DL560 Gen10 Entry,DL560 Gen10 Performance,DL560 Gen9,DL560 Gen9 Base,DL560 Gen9 Entry,DL560 Gen9 Performance,DL580 Gen10,DL580 Gen10 Base,DL580 Gen10 Entry,DL580 Gen10 Performance,DL80 Gen9 Entry,ML10 Gen9,ML10 Gen9 Entry,ML10 Gen9 Performance,ML10 v2,ML10 v2 Base,ML10 v2 Entry,ML10 v2 Performance,ML110 Gen10,ML110 Gen10 Entry,ML110 Gen10 Performance,ML110 Gen10 Solution,ML110 Gen9,ML110 Gen9 Base,ML110 Gen9 Entry,ML30 Gen10,ML30 Gen10 Entry,ML30 Gen10 Performance,ML30 Gen10 Solution,ML30 Gen9,ML30 Gen9 Base,ML30 Gen9 Entry,ML30 Gen9 Performance,ML30 Gen9 Solution,ML350 Gen10,ML350 Gen10 Base,ML350 Gen10 Entry,ML350 Gen10 High Performance,ML350 Gen10 Performance,ML350 Gen10 SMB,ML350 Gen10 Solution,ML350 Gen10 Sub-Entry,ML350 Gen9 Base,ML350 Gen9 Entry,ML350 Gen9 Performance,ML350p Gen8,XL170r Gen9,XL190r Gen9,XL230k Gen10 Compute Tray,XL270d Gen9,XL450 Gen10
HPE SimpliVity 380 Gen9 Node
HPE StoreEasy 1450,1850,3850 Gateway Single Node
